فلاشة نادره جدا I9060 4.1.2 MT6572

**MOHAMED*GSM** · 29-03-2017, 06:34 PM

الجيماويه الكرام تستمر

المفاجأت والحصريات ع الجيم

الحبيب الغالي اليوم فلاشة

I9060 4.1.2

لعيون الجيماويه جميعا

وكي تعم الفائده للجميع

اغلب الاجهزه التي تحمل نفس معلومات

هاي الفلاشة لاحظت تعالج مشاكلها بفلاشة

اخري لنفس الموديل ومتطابقة في الادريسات بس

النظام الذي تعمل بيه هو 4.4.4

وليس 4.1.2

تمام لحدي هنا بس مع الاسف ماتوفر لي انفو لها
ولاكن سأكتفي برفع معلومات الاسكاتر ::::

كود:

############################################################################################################
#
#  General Setting
#
############################################################################################################
- general: MTK_PLATFORM_CFG
  info:
    - config_version: V1.1.1
      platform: MT6572
      project: mbk72_wet_lca
      storage: EMMC
      boot_channel: MSDC_0
      block_size: 0x20000
############################################################################################################
#
#  Layout Setting
#
############################################################################################################
- partition_index: SYS0
  partition_name: PRELOADER
  file_name: preloader_mbk72_wet_lca.bin
  is_download: true
  type: SV5_BL_BIN
  linear_start_addr: 0x0
  physical_start_addr: 0x0
  partition_size: 0x600000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: BOOTLOADERS
  reserve: 0x00

- partition_index: SYS1
  partition_name: MBR
  file_name: MBR
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x600000
  physical_start_addr: 0x600000
  partition_size: 0x80000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS2
  partition_name: EBR1
  file_name: EBR1
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x680000
  physical_start_addr: 0x680000
  partition_size: 0x80000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS3
  partition_name: PRO_INFO
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0x700000
  physical_start_addr: 0x700000
  partition_size: 0x300000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: PROTECTED
  reserve: 0x00

- partition_index: SYS4
  partition_name: NVRAM
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0xA00000
  physical_start_addr: 0xA00000
  partition_size: 0x500000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: BINREGION
  reserve: 0x00

- partition_index: SYS5
  partition_name: PROTECT_F
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0xF00000
  physical_start_addr: 0xF00000
  partition_size: 0xA00000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: PROTECTED
  reserve: 0x00

- partition_index: SYS6
  partition_name: PROTECT_S
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0x1900000
  physical_start_addr: 0x1900000
  partition_size: 0xA00000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: PROTECTED
  reserve: 0x00

- partition_index: SYS7
  partition_name: SECCFG
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0x2300000
  physical_start_addr: 0x2300000
  partition_size: 0x20000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: INVISIBLE
  reserve: 0x00

- partition_index: SYS8
  partition_name: UBOOT
  file_name: lk.bin
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x2320000
  physical_start_addr: 0x2320000
  partition_size: 0x60000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS9
  partition_name: BOOTIMG
  file_name: boot.img
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x2380000
  physical_start_addr: 0x2380000
  partition_size: 0x600000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS10
  partition_name: RECOVERY
  file_name: recovery.img
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x2980000
  physical_start_addr: 0x2980000
  partition_size: 0x600000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS11
  partition_name: SEC_RO
  file_name: secro.img
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x2F80000
  physical_start_addr: 0x2F80000
  partition_size: 0x40000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS12
  partition_name: MISC
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0x2FC0000
  physical_start_addr: 0x2FC0000
  partition_size: 0x80000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: INVISIBLE
  reserve: 0x00

- partition_index: SYS13
  partition_name: LOGO
  file_name: logo.bin
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x3040000
  physical_start_addr: 0x3040000
  partition_size: 0x300000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS14
  partition_name: EXPDB
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0x3340000
  physical_start_addr: 0x3340000
  partition_size: 0xA00000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: INVISIBLE
  reserve: 0x00

- partition_index: SYS15
  partition_name: ANDROID
  file_name: system.img
  is_download: true
  type: EXT4_IMG
  linear_start_addr: 0x3D40000
  physical_start_addr: 0x3D40000
  partition_size: 0x1E000000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS16
  partition_name: CACHE
  file_name: cache.img
  is_download: true
  type: EXT4_IMG
  linear_start_addr: 0x21D40000
  physical_start_addr: 0x21D40000
  partition_size: 0x1B00000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS17
  partition_name: USRDATA
  file_name: userdata.img
  is_download: true
  type: EXT4_IMG
  linear_start_addr: 0x23840000
  physical_start_addr: 0x23840000
  partition_size: 0x19000000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS18
  partition_name: FAT
  file_name: fat.img
  is_download: true
  type: NORMAL_ROM
  linear_start_addr: 0x3C840000
  physical_start_addr: 0x3C840000
  partition_size: 0x326E0000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: true
  is_reserved: false
  operation_type: UPDATE
  reserve: 0x00

- partition_index: SYS19
  partition_name: BMTPOOL
  file_name: NONE
  is_download: false
  type: NORMAL_ROM
  linear_start_addr: 0xFFFF00A8
  physical_start_addr: 0xFFFF00A8
  partition_size: 0x1500000
  region: EMMC_USER
  storage: HW_STORAGE_EMMC
  boundary_check: false
  is_reserved: true
  operation_type: RESERVED
  reserve: 0x00

رابط الفلاشة
https://www.4shared.com/rar/1kkb2m2l..._MOHAMED-.html

باسورد الدخول
mohamedgemflash.com

باسورد فك الضغط
www.gem-flash.com

مع تحيااااتي
