رجاء المساعدة في حل هذه المشكلة
فيه عندي جهاز سمسونك GT-9060I كان واقف على اللوكو
بعد مامرت ملفاة د
ANDROID BaseAddr:0x4340000 Size:0x28A00000
USRDATA BaseAddr:0x44540000 Size:0x2C000000
شتقل لاكن مافيه صوت و لا شبكة
بعدين مررت فلاشة كاملة بهذه البيات التاليةCPU: MT6572 SW:0000 Ver: CA01اشتغل تمام فيه شبكة لا كن مافيه صوت
Downloading Boot8 ...
EMMC Size: 0x00E6800000
Flash Type: EMMC
INT/EXT RAM Size: 0x0+0x0
Reading infr(EMMC)...
PRELOADER BaseAddr:0x0 Size:0xC00000
MBR BaseAddr:0xC00000 Size:0x80000
EBR1 BaseAddr:0xC80000 Size:0x80000
PRO_INFO BaseAddr:0xD00000 Size:0x300000
NVRAM BaseAddr:0x1000000 Size:0x500000
PROTECT_F BaseAddr:0x1500000 Size:0xA00000
PROTECT_S BaseAddr:0x1F00000 Size:0xA00000
SECCFG BaseAddr:0x2900000 Size:0x20000
UBOOT BaseAddr:0x2920000 Size:0x60000
BOOTIMG BaseAddr:0x2980000 Size:0x600000
RECOVERY BaseAddr:0x2F80000 Size:0x600000
SEC_RO BaseAddr:0x3580000 Size:0x40000
MISC BaseAddr:0x35C0000 Size:0x80000
LOGO BaseAddr:0x3640000 Size:0x300000
EXPDB BaseAddr:0x3940000 Size:0xA00000
ANDROID BaseAddr:0x4340000 Size:0x28A00000
CACHE BaseAddr:0x2CD40000 Size:0x17800000
USRDATA BaseAddr:0x44540000 Size:0x2C000000
FAT BaseAddr:0x70540000 Size:0x751E0000
BMTPOOL BaseAddr:0xFFFF0000 Size:0x1500000
BaseAddr:0x0 Size:0x0
>>Done.
جربت افلش ملف اندرويد و اليوزر من فلاشة سمسونك G350H
ANDROID BaseAddr:0x4340000 Size:0x28A00000
USRDATA BaseAddr:0x44540000 Size:0x2C000000
واخير شتقل الصوة
لاكن الصورة طلعت امخربط
ولا فيه شبكة
اريد المساعدة رجاء
وهذه هي بيات الهاتف لأصلية
والله ولي التوفيقكود:############################################################################################################ # # General Setting # ############################################################################################################ - general: MTK_PLATFORM_CFG info: - config_version: V1.1.1 platform: MT6572 project: mtk_android storage: EMMC boot_channel: MSDC_0 block_size: 0x20000 ############################################################################################################ # # Layout Setting # ############################################################################################################ - partition_index: SYS0 partition_name: PRELOADER file_name: preloader.bin is_download: true type: SV5_BL_BIN linear_start_addr: 0x0 physical_start_addr: 0x0 partition_size: 0xC00000 region: EMMC_BOOT_1 storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: BOOTLOADER reserve: 0x00 - partition_index: SYS1 partition_name: MBR file_name: MBR.bin is_download: true type: NORMAL_ROM linear_start_addr: 0xC00000 physical_start_addr: 0x0 partition_size: 0x80000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS2 partition_name: EBR1 file_name: EBR1.bin is_download: true type: NORMAL_ROM linear_start_addr: 0xC80000 physical_start_addr: 0x0 partition_size: 0x80000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS3 partition_name: PRO_INFO file_name: NONE is_download: false type: NONE linear_start_addr: 0xD00000 physical_start_addr: 0x0 partition_size: 0x300000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: PROTECTED reserve: 0x00 - partition_index: SYS4 partition_name: NVRAM file_name: nvram.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x1000000 physical_start_addr: 0x0 partition_size: 0x500000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS5 partition_name: PROTECT_F file_name: protect_f.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x1500000 physical_start_addr: 0x0 partition_size: 0xA00000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS6 partition_name: PROTECT_S file_name: protect_s.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x1F00000 physical_start_addr: 0x0 partition_size: 0xA00000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS7 partition_name: SECCFG file_name: NONE is_download: false type: NONE linear_start_addr: 0x2900000 physical_start_addr: 0x0 partition_size: 0x20000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: INVISIBLE reserve: 0x00 - partition_index: SYS8 partition_name: UBOOT file_name: uboot.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x2920000 physical_start_addr: 0x0 partition_size: 0x60000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS9 partition_name: BOOTIMG file_name: bootimg.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x2980000 physical_start_addr: 0x0 partition_size: 0x600000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS10 partition_name: RECOVERY file_name: recovery.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x2F80000 physical_start_addr: 0x0 partition_size: 0x600000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS11 partition_name: SEC_RO file_name: secro.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x3580000 physical_start_addr: 0x0 partition_size: 0x40000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS12 partition_name: MISC file_name: misc.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x35C0000 physical_start_addr: 0x0 partition_size: 0x80000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS13 partition_name: LOGO file_name: logo.bin is_download: true type: NORMAL_ROM linear_start_addr: 0x3640000 physical_start_addr: 0x0 partition_size: 0x300000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS14 partition_name: EXPDB file_name: NONE is_download: false type: NONE linear_start_addr: 0x3940000 physical_start_addr: 0x0 partition_size: 0xA00000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: INVISIBLE reserve: 0x00 - partition_index: SYS15 partition_name: ANDROID file_name: system.bin is_download: true type: YAFFS_IMG linear_start_addr: 0x4340000 physical_start_addr: 0x0 partition_size: 0x28A00000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS16 partition_name: CACHE file_name: cache.bin is_download: true type: YAFFS_IMG linear_start_addr: 0x2CD40000 physical_start_addr: 0x0 partition_size: 0x17800000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS17 partition_name: USRDATA file_name: userdata.bin is_download: true type: YAFFS_IMG linear_start_addr: 0x44540000 physical_start_addr: 0x0 partition_size: 0x2C000000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS18 partition_name: FAT file_name: fat.bin is_download: true type: YAFFS_IMG linear_start_addr: 0x70540000 physical_start_addr: 0x0 partition_size: 0x751E0000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: true is_reserved: false operation_type: UPDATE reserve: 0x00 - partition_index: SYS19 partition_name: BMTPOOL file_name: NONE is_download: false type: NONE linear_start_addr: 0xFFFF00A8 physical_start_addr: 0x0 partition_size: 0x1500000 region: EMMC_USER storage: HW_STORAGE_EMMC boundary_check: false is_reserved: true operation_type: RESERVED reserve: 0x00
